knife edge valve

1,000.00 - 1,500.00 / Piece

1 Piece (MOQ)

Business Type Manufacturer, Exporter, Importer
Country of Origin India,India
Size 100-150mm, 150-200mm, 200-250mm, 250-300mm, 300-350mm, 350-400mm, 400-450mm, 450-500mm, 50-100mm,50-100mm
Type Knife Edge Gate Valve,Knife Edge Gate Valve
Click to view more

Preferred Buyer From

Location All Countries Except India

Product Details

Brand Name
MATOS
Material
Alloy Steel, Carbon Steel, Stainless Steel,Stainless Steel,SS304 (CF8), SS316L (CF3M), Hast Alloy, SS316 (CF8M), Alloy Steel, Cast Iron IS210 Gr. FG200, SS304L (CF3)
Certification
ISO 9001:2008 Certified,ISO 9001:2008 Certified
Application
Oil Fitting, Water Fitting
Feature
Durable
Condition
New,New
Pressure
High, Low, Medium
End Connection
Flanged, Wafer and Lug Type,Flanged
Structure
Api
Media
Slurry, Powder, Fly Ash, Cement
Operation
Hand Wheel / Pneumatic Actuator / Cylinder / Electric Actuator
Size Range
2
Surface Treatment
Casting
Packaging Details
Wooden Case
Port
UAE, DUBAI, JABAL ALI
Power
Pneumatic
Flanges standard
Class 150 / customer requirement
Available size
100mm to 600mm
Body
ASTM A 351 Gr. CF 8/CF 8M/ Combination of WCB & SS
Gate
SS316, Duplex, SS304
Stem
EN-8 / Stainless Steel AISI 304 / 316 / 310
Working Pressure
10 Bar - 24 Bar
Body Material
CI, HASTELLOY C276, MONEL, WCB, CF8, CK20, CF8M
Usage/Application
Slurry
Finish
Industry (optional: Mirror Finish for Pharma)
End Configurations
WAFER TYPE
Testing Standard
MSS SP 81
End Connections
Wafer Type I Wafer Lugged I Semi Lugged
Knife Plate
SS 304 I SS 316
Seat
Teflon, Nitrile (Silicon, & Metal Seated on request), Vitron, EPDM
LESS PRICES
Quick delivery
Ansi Class / Rating
150#/PN 10
Design Standard
MSS SP-81
SIZE RANGE
3
MOC / BODY
C.I. / D.I. / WCB./ CF8/CF8M & ALLOY STEEL
API 600
API 598
Disc
SS 316 / SS 304 / WCB
Gasket & Packing
PTFE/ Graphite/ Asbestos etc.
Port Opening
Full
Actuator
Hand Wheel / Pneumatic cylinder / Electrical Actuator
Rating
PN 6, PN 10, 150#
Ends
Wafer / Lugged / Flanged
DESIGN STANDARD
MSS SP 81
OPERATION
HAND WHEEL / GEAR / PNEUMATIC /ELECTRIC ACTUATOR OPERATED
Material Specification
  Body
  C.I, WCB CF8, CF8M
  Gate
  ANSI 304 AISI 316
  Seat
Payment Terms
D/A, D/P, T/T

"MATOS" Make Knife Egde Gate Vales Soft and Metal to Metal Seated.
